伴隨著我國工業現代化的飛速發展，以中央提出的供給側改革和工業4.0為指導思想，工業產品的思路正由量變向質變突破。模型制造業作為工業領域的服務業需求，也能更好地滿足現代工業的需求。工業模型又稱手版模型，主要生產方法有數控加工、激光成型和硅膠模型小批量生產，廣泛應用于工業新產品的設計和研發階段。用較短的時間加工和設計與實物一致的模型，這樣設計師就可以進行產品外觀確認和功能測試，從而完善設計方案。減少開發成本，縮短開發周期，快速獲得客戶認可。那么工業模型到底是怎么制作的呢？

With the rapid development of China's industrial modernization, with the central government's supply side reform and industry 4.0 as the guiding ideology, the idea of industrial products is breaking through from quantitative change to qualitative change. As the demand of service industry in industry, model manufacturing industry can better meet the demand of modern industry. Industrial model, also known as hand model, is widely used in the design and R & D stage of new industrial products. In this way, the designer can confirm the appearance and test the function of the product, so as to improve the design scheme. Reduce the development cost, shorten the development cycle, quickly get customer recognition. So how is the industrial model made?

工業模型制造的基本過程。

The basic process of industrial model manufacturing.

1.設計圖紙:根據自己的要求設計圖紙。

1. Design drawings: design drawings according to your own requirements.

2.顏色選擇噴漆:根據圖紙設置相應顏色的油漆，噴涂在相應的聚氯乙烯板或3D打印模型上。聚氯乙烯板需要送到相關部門進行雕刻。

2. Color selection painting: according to the drawing set the corresponding color of paint, spray on the corresponding PVC board or 3D printing model. PVC sheet needs to be sent to relevant departments for carving.

3.雕刻部件:結構根據實際情況按比例設計，在電腦上分解成不同的板塊，按照圖紙按一定比例縮小，雕刻板塊，用三氯甲烷粘合。

3. Carving parts: the structure is designed according to the proportion according to the actual situation. It is decomposed into different plates on the computer. It is scaled down according to the drawing. The plates are carved and glued with chloroform.

組合部件：按照指導說明和粘接方式，用三氯甲烷將PVC板粘接成工業模型的大致形狀。

Assembly parts: according to the instruction and bonding method, use chloroform to bond the PVC board into the approximate shape of the industrial model.

5.整體組合:配件制作和模型組合。

5. Overall combination: parts making and model combination.

工業機械模型從接到訂單開始基本操作，現在可以利用各種設備進行前期準備，追求精致產品，可以說是從簡單到精致的過程。模型種類中工業模型是常見的一種，制作工業模型對制造商和設計公司具有非常重要的意義。

The basic operation of industrial machinery model starts from receiving the order. Now we can use all kinds of advanced equipment for preliminary preparation and pursue exquisite products. It can be said that it is a process from simple to exquisite. Industrial model is one of the most common types of models. It is very important for manufacturers and design companies to make industrial models.

(1)檢查外觀設計

(1) Check the design

視覺與觸覺的雙重效應是工業模型走向精良的重要環節，它不僅能直觀地以實物的形式反映設計師的創意，而且避免了“畫得好看，做得不好看”的弊端。由于工業模型在制作前，對產品造型進行推敲是必不可少的。

The dual effect of vision and touch is an important link in the development of industrial model. It can not only intuitively reflect the designer's creativity in the form of real objects, but also avoid the disadvantages of "good-looking painting, not good-looking doing". As the industrial model in the production, the product modeling is essential.

(2)是檢驗結構設計

(2) It's about checking structural design

由于工業模型是可組裝的特性，可以更直觀地反映結構的合理性和安裝難度。方便制造商或設計公司盡快發現問題并解決問題。

Because the industrial model can be assembled, it can more directly reflect the rationality of the structure and the difficulty of installation. It is convenient for manufacturers or design companies to find and solve problems as soon as possible.

(3)避免直接打開模具的風險

(3) Avoid the risk of opening the mold directly

由于模具制造成本普遍較高，相對較大且獨特的模具價值數十萬甚至數百萬，如果在開模過程中發現結構不合理或其他問題，其損失可想而知。工業模型可以避免這種損失，降低開模風險。

Due to the high cost of mold manufacturing, the relatively large and unique mold is worth hundreds of thousands or even millions. If the structure is unreasonable or other problems are found in the process of mold opening, the loss can be imagined. The industrial model can avoid this loss and reduce the risk of mold opening.

(4)大大提前產品上市

(4) Product launch ahead of time

工業模型制作的性，不僅可以在模具開發前利用工業模型進行產品宣傳，還可以進行前期銷售、生產準備，工業模具可以以其優勢盡快占領市場

The advanced nature of industrial model can not only promote product publicity before the development of the mold, but also provide pre sale and production preparation. Industrial mold can occupy the market as soon as possible with its advantages.

工業模型都是非標產品，不能批量生產，都是根據客戶的要求量身定做的，凡是加工制作零件，不規則零件，肯定比規則零件難。而且越不規則，結構要求越復雜越精細，對模型制作企業的要求也越高。

Industrial models are all non-standard products, which can not be mass produced. They are all customized according to the requirements of customers. It is certainly more difficult to process irregular parts than regular parts. Moreover, the more irregular the structure is, the more complex and refined the structure requirements are, and the higher the requirements are for the model making enterprises.
